Chinese grade: GH1015 iron-based superalloy
Material : GH1015
One. Overview of GH1015 iron-based high temperature alloy steel:
GH1015 superalloy is a solid solution strengthened iron-based superalloy steel composed of nickel, molybdenum, niobium and other elements, with a nickel content of about 38%. GH1015 superalloy has good hot and cold workability, good combination of strength and plasticity at various temperatures, high thermal strength, good thermal fatigue and oxidation resistance; its stamping, welding and other process properties are good . It has a time effect in long-term use.
Two. Chemical composition of GH1O15 iron-based superalloy: see table-1
Three, GH1015 high temperature alloy steel mechanical properties:
Heat treatment system: 1140-11700c air cooling
Fourth, GH1015 high temperature alloy steel use:
It is suitable for the manufacture of general load-bearing parts (except turbine blades) for aerospace, aviation, gas turbines and other industries with a temperature of 550-1000°C, and for turbine engine combustion chambers and afterburners working below 950°C. .
Five. Species, specifications and supply status of GH1015:
1. Variety classification: GH1015 seamless pipe, GH1015 steel plate, GH1015 round steel, GH1015 forgings, GH1015 flange, GH1015 ring, GH1015 welded pipe, GH1015 steel strip, GH1015 wire and GH1015 matching welding materials.
2. Delivery status:
Seamless tube: solid solution + acid white, length can be set;
Board: solid solution, pickling, trimming;
Welded pipe: solid solution acid white + RT% flaw detection,
Forgings: Annealing + car light;
The bar is in the forged and rolled state, the surface is polished or car polished;
The strip is cold-rolled, solid-solution softened, deoxidized and delivered;
The wire is delivered in a solid solution pickled disk shape or a straight strip shape, and a solid solution straight strip in a finely polished state.
Chinese grade: GH1015 iron-based superalloy
Material : GH1015
One. Overview of GH1015 iron-based high temperature alloy steel:
GH1015 superalloy is a solid solution strengthened iron-based superalloy steel composed of nickel, molybdenum, niobium and other elements, with a nickel content of about 38%. GH1015 superalloy has good hot and cold workability, good combination of strength and plasticity at various temperatures, high thermal strength, good thermal fatigue and oxidation resistance; its stamping, welding and other process properties are good . It has a time effect in long-term use.
Two. Chemical composition of GH1O15 iron-based superalloy: see table-1
| Grade | Chemical Composition | ||||||||
| GH1015 | C≤ | Si≤ | Mn≤ | P≤ | S≤ | Cr≥ | Ni≥ | Mo≥ | Cu≤ |
| 0.08 | 0.60 | 1.50 | 0.020 | 0.015 | 19.0-22.0 | 34.0-39.0 | 2.50-3.20 | - | |
| Other | N≤ | Al≤ | Ti≤ | Fe≤ | B≤ | Ce≤ | W≤ | Nb≤ | |
| - | - | - | The remaining amount | 0.01 | 0.05 | - | - | ||
Table 1
Three, GH1015 high temperature alloy steel mechanical properties:
Heat treatment system: 1140-11700c air cooling
| Grade | Physical Properties | |||
| GH1015 | Tensile strength(MPa) | Yield Strength(MPa) | Elongation(%) | Rate of reduction in area(%) |
| ≥680 | ≥630 | ≥35 | ≥40 | |
Fourth, GH1015 high temperature alloy steel use:
It is suitable for the manufacture of general load-bearing parts (except turbine blades) for aerospace, aviation, gas turbines and other industries with a temperature of 550-1000°C, and for turbine engine combustion chambers and afterburners working below 950°C. .
Five. Species, specifications and supply status of GH1015:
1. Variety classification: GH1015 seamless pipe, GH1015 steel plate, GH1015 round steel, GH1015 forgings, GH1015 flange, GH1015 ring, GH1015 welded pipe, GH1015 steel strip, GH1015 wire and GH1015 matching welding materials.
2. Delivery status:
Seamless tube: solid solution + acid white, length can be set;
Board: solid solution, pickling, trimming;
Welded pipe: solid solution acid white + RT% flaw detection,
Forgings: Annealing + car light;
The bar is in the forged and rolled state, the surface is polished or car polished;
The strip is cold-rolled, solid-solution softened, deoxidized and delivered;
The wire is delivered in a solid solution pickled disk shape or a straight strip shape, and a solid solution straight strip in a finely polished state.
